Partition walls · Single-Pane Glass Walls
J’Clickd
Jansen Wall Solutions.
Modular single-pane partition wall with a patented steel snap-fit system for flexible spaces.
<ul>
<li>Next-level flexibility</li>
<li>Sustainable</li>
<li>Dismountable</li>
<li>Quick to install</li>
<li>Curved options available</li>
</ul>
Technical Specifications
Dimensions / Sizes
Wall thickness: 60 mm. Profile: 60 x 50 mm. Glass thicknesses: 10, 12, or 16 mm. Tolerance: max. 30 mm.
Materials / Composition
Acoustic laminated glass, steel snap-fit profiles, finish available upon request
Acoustic Performance
Rw 31 dB at 10 mm, 37 dB at 12 mm, 39 dB at 16 mm
Options & Variants
J'Swing Framed Single-Glazed Door 40 mm, J'Swing Solid Door 40 mm, J'Swing Single-Glazed Door 40 mm, J'Slide Options
Additional Technical Specifications
Weight: 25, 30, or 40 kg/m², depending on glass thickness. Ceiling track and floor track with a steel click system.
Video
<p><iframe title="J'Clickd I Jansen Wall Solutions" width="1080" height="608" src="https://www.youtube.com/embed/ZRRS3U6f9s8?feature=oembed"></iframe></p>
Documentation
Images
Available variants
Discover all the models in this product group.
| Variant | Materiaal | Dikte | Hoogte | Akoestiek |
|---|---|---|---|---|
J'Clickd Alu 50
|
Aluminum (RAL) | approx. 52 mm | 3,500 mm | 36/39 dB * |
Jansen Wall Solutions.
|
Jansen Wall Solutions. | 60 mm | 3,000 mm | 36/39 dB * |
J'Clickd Solid
|
Bamboo, rubberwood, HPL | 100 mm | 3,500 mm | 50 dB |
<p>Alu 50 and Wood 60: single-pane glass. Solid: solid-panel design. </p>
<p>* Depending on the wall composition. Acoustic reports are available. </p>
